AIRMATE

Durable airmate, accurate airmate, trusted after-sales service

  • Products
  • Specification and Configuration
  • Need for Airmate
  • Automtic Functions of Airmate
    • Standard configuration
    • AIRMATE body
    • 10M hose (air chuck connection)
    • 1 hose hanger
    • 1 manual
    Options
    • Stand
    • Mobile cart
    • One-moment stop function for large tires (ZIPPER-RUPTURE Program)
    • One-moment stop function for small tires (Safety Check Program)
    • Air pressure check function (Accuracy test mode)
    • Winter heater(PTC Headter)
    Technical Specifications
    Operation and Initial Pressure
    • : TM100 5-100 PSI(Operating Pressure ) 30PSI(Initial Set Value )
    •   TM150 5-150 PSI(Operating Pressure) 120PSI(Initial Set Value)
    Maximum Input Air Pressure
    : 231 PSI
    Required Supply Air Pressure
    : Target Value + 10 PSI
    Accuracy
    : ± 1 PSI
    Power
    : 220VAC, 60Hz, 16W
    Pressure Unit
    : PSI (BAR)
    Pressure Display
    : DUAL DISPLAY(Constant Pressure and Current Pressure ), 7-DIGIT VFD
    Operating Temperature
    : -10℃ ~ 50℃
    Body Weight
    • : TM100/150 -5Kg
    •   TM150W -8.2Kg
    Product Size
    : (W x L x H) TM100/150 : 250 x 150 x 200mm / TM150W : 360 x 150 x 200mm
    HEATER
    : PTC (Positive Temperature Coefficent), Operating temperature : 5℃ ~ 15℃
    LABEL
